Acue Lighting Legend 230 7R Double Prism Beam Moving Head — Dual-Prism Beam Performance

Legend 230 Overview

The Acue Lighting Legend 230 is a professional beam moving head built around a 230W 7R lamp at 6100K, delivering high-output beam performance suited for touring production, rental inventory, and permanent venue installations. Its defining feature is a dual-prism configuration combining a 1×24-facet circular rotating prism and a 1×7-facet linear rotating prism, which can be used simultaneously to produce a distinctive 3D beam effect not achievable with standard single-prism fixtures. With 17-channel DMX control, the Legend 230 supports full parameter automation including focus, frost, dimmer, and shutter. This fixture is a proven choice for production companies and lighting integrators requiring reliable, feature-rich beam fixtures at scale.

The Legend 230 is sold as a package including two fixtures and a flight case, making it a practical acquisition for rental operations and touring rigs. It accepts universal input voltage from 110–220V AC via PowerCon connection, supporting deployment across varied power environments.

Key Features

• Dual Rotating Prism System — 1×24-facet circular rotating prism and 1×7-facet linear rotating prism operate independently or simultaneously for layered 3D beam effects
• 230W 7R Light Source — 6100K color temperature lamp with a rated 2,000-hour lamp life
• 14-Color Wheel + White — includes a rainbow color filter for smooth color transitions across the full wheel
• 17 Gobos + Open — gobo wheel with 17 positions plus open for beam shaping flexibility
• Mechanical Linear Frost Control — 0–100% frost adjustable by DMX for beam diffusion without additional fixtures
• Automated DMX Focus — motorized focus control via DMX for precise beam definition at varying throw distances
• 4 Shutter Modes — DMX-adjustable strobe with four distinct shutter modes for dynamic effects
• Multiple Operating Modes — DMX, Auto-Program, Master/Slave, and Sound Activated modes for flexible deployment in any environment
• Package Includes Flight Case — sold as a two-fixture package with a road-ready flight case for transport and storage

Connectivity & I/O

• 3-pin DMX input connector
• 3-pin DMX output connector (DMX thru)
• PowerCon power input connection (110–220V AC 50/60 Hz)

Technical Specifications
