FBT MUSE 210L — 2×10″ Passive Line Array Module
MUSE 210L Overview
The FBT MUSE 210L is a passive line array module engineered for professional sound reinforcement in demanding vertical deployment scenarios. Rated at 800W LF and 200W RMS HF, the enclosure houses two custom 10″ long-excursion woofers with 2.5″ voice coils alongside two 1″ B&C compression drivers mounted on a proprietary waveguide, delivering a frequency response of 60Hz to 18kHz and a maximum SPL of 135dB. The MUSE 210L is purpose-built for concert tours, outdoor festivals, theaters, and fixed installations where consistent, phase-coherent coverage across scalable configurations is required. It is designed for use with external amplifiers and dedicated system processors such as the FBT DLM series.
The MUSE 210L’s modular architecture allows integrators and touring engineers to scale arrays precisely to venue demands, while its NL4 Speakon rear-panel connectivity ensures secure, reliable signal routing in both input and link configurations.
Key Features
- Dual 10″ Long-Excursion Woofers — Two custom 10″ drivers with 2.5″ voice coils provide extended low-frequency output and controlled excursion under high-power conditions
- Dual 1″ B&C Compression Drivers — High-frequency transducers mounted on a proprietary waveguide for consistent, detailed HF reproduction
- 90° Horizontal Dispersion — Proprietary waveguide geometry delivers a defined 90° horizontal coverage pattern with tightly controlled vertical projection for precise audience coverage
- 800W LF / 200W RMS HF Power Handling — Passive design supports high-power amplification from external amplifiers, enabling flexible system configuration
- 135dB Maximum SPL — Suitable for high-output applications including outdoor festivals and large-format concert touring
- 60Hz – 18kHz Frequency Response — Full-range coverage in a line array format without requiring supplemental high-frequency elements in standard configurations
- NL4 Speakon Connectivity — Rear-panel NL4 connectors for both input and link connections ensure secure, roadworthy signal routing
- Modular Scalability — Designed for vertical array deployment with phase-coherent performance across multi-module configurations, compatible with FBT DLM series processors
Connectivity & I/O
- NL4 Speakon input connector (rear panel)
- NL4 Speakon link connector (rear panel)
