ProX XZF-WLV1CL2 ZCASE Flip-Ready Hydraulic Console Case for Waves eMotion LV1 Classic
XZF-WLV1CL2 Overview
The ProX XZF-WLV1CL2 is a Flip-Ready ATA-300 road case designed specifically for the Waves eMotion LV1 Classic console, distributed exclusively by ProX North America and handcrafted in Poland by ZCASE. The gas-powered rotational hydraulic lift mechanism allows a single technician to raise the console into operating position with minimal effort, eliminating the need for a second person during load-in. The case is constructed from 9mm hexagonal birch plywood with Penn Elcom medium hardware and features a Honeycomb Digital surface laminate that resists scuffs and scrapes in demanding touring environments. This case is engineered for FOH engineers, touring companies, and system integrators who require reliable, ergonomic console deployment at live events.
A large doghouse storage area with left and right cable routing openings, an integrated laptop shelf with arm holder, dual mouse pads, and a front-accessible 2U 19″ rack space provide a complete, self-contained workstation solution within a single rolling case.
Key Features
- Flip-Ready Hydraulic Lift Mechanism — ZCASE patented gas-powered rotational system raises the console to operating position with single-finger effort, no heavy lifting required
- Single-Operator Deployment — eliminates the need for a second person during transport, roll-in, and setup at FOH positions
- ATA-300 Road Case Construction — built from 9mm hexagonal birch plywood with 1/2″ and 3/8″ plywood components and Penn Elcom medium hardware
- Honeycomb Digital Surface Laminate — signature hexagonal pattern finish protects against minor scuffs and scrapes in touring conditions
- Integrated 2U Rack Space — 19″ rack rails with 19.2″ front-to-back rail spacing, accessible from the front of the case
- Doghouse Storage Area — 5.9″ deep with left and right openings for cable routing and accessory storage; door storage compartment measuring 22″ x 6.2″ x 13″
- Console Fader Height — positions faders at 37.4″ for ergonomic standing operation
- Laptop Shelf and Mouse Pads — includes 1 arm holder with laptop shelf and 2 mouse pads for a complete operator workstation
- New Shock Absorbent System — updated internal suspension protects the console during transport
- Individually Tested — each unit quality-checked and function-tested at the ZCASE facility in Poland before shipment
Technical Specifications
| Compatible Console | Waves eMotion LV1 Classic |
| Outer Dimensions (W x D x H) | 31.7″ x 23.6″ x 40.2″ |
| Console Fader Height | 37.4″ |
| Doghouse Depth | 5.9″ |
| Door Storage Compartment (W x D x H) | 22″ x 6.2″ x 13″ |
| Rack Space | 2U, 19″ rack, 19.2″ rail depth |
| Case Weight (Empty) | 160 lbs |
| Case Construction | 9mm hexagonal birch plywood, 1/2″ and 3/8″ plywood |
| Hardware | Penn Elcom medium hardware |
| Surface Finish | Honeycomb Digital hexagonal pattern laminate |
| Lift Mechanism | Gas-powered rotational hydraulic (ZCASE patent pending) |
| Origin | Handcrafted in Poland by ZCASE |
| ATA Rating | ATA-300 |
