K&M 24173 Speaker Wall Mount — Heavy-Duty Steel, Black

24173 Overview

The K&M 24173 is a robust steel speaker wall mount engineered for permanent installation of speaker cabinets equipped with a standard flange socket receptacle. Built for professional fixed installations in venues, houses of worship, broadcast facilities, and commercial AV environments, it supports a maximum recommended load of 25 kg and offers a 140° swivel range for precise horizontal coverage adjustment. The 0° to -30° angle of inclination allows downward tilt to optimize speaker aim toward the listening area. This mount is well suited for system integrators and installers who require a clean, durable solution with minimal visual footprint.

The bracket profile is designed so that the mounted speaker cabinet largely conceals the hardware, resulting in a clean finished appearance in architectural and permanent install settings. The 220 x 120 mm wall plate provides a stable mounting footprint across standard wall surfaces.

Key Features

• High Load Capacity — supports a maximum recommended load of 25 kg, suitable for a wide range of full-range and satellite speaker cabinets
• 140° Swivel Adjustment — wide horizontal rotation range allows precise speaker aiming for coverage optimization in asymmetrical or complex room geometries
• 0° to -30° Tilt Range — downward inclination adjustment directs sound toward the listening plane for ceiling-height or elevated wall installations
• Standard Flange Socket Compatibility — 35 mm diameter x 85 mm mounting bolt interfaces with speaker cabinets featuring a standard flange socket receptacle
• All-Steel Construction — full steel build provides long-term structural integrity in permanent installation environments
• Low-Profile Design — bracket geometry is largely concealed by the mounted speaker cabinet, minimizing visual impact in finished spaces
• Multiple Wall-to-Bolt Clearance Options — adjustable positions at 172, 202, 232, and 262 mm accommodate varying cabinet depths and installation requirements
• Generous Wall Clearance — 499 mm wall clearance provides adequate standoff for larger cabinet profiles

Connectivity & I/O

• Wall plate: 220 x 120 mm, attaches to wall surface via standard fasteners
• Mounting bolt: 35 mm diameter x 85 mm, compatible with standard flange socket receptacle on speaker cabinets
