K&M 24357 Speaker Wall Mount Adapter Plate 4 — Horizontal Bracket for Fixed Speaker Installations
24357 Overview
The K&M 24357 Adapter Plate 4 is a purpose-built steel wall mount bracket designed for horizontal speaker placement in permanent installation environments. The plate provides a 128 x 90 mm bearing surface and is engineered around a 107.9 x 50.8 mm M6 mounting pattern, ensuring compatibility with a wide range of installation speakers. At just 0.2 kg, this bracket is suited for system integrators, installers, and venues requiring a clean, low-profile mounting solution.
Constructed from steel, the 24357 offers the structural integrity expected in permanent AV installations, and the included mounting template simplifies accurate wall positioning during installation.
Key Features
- Steel Construction — Provides the rigidity and durability required for permanent speaker mounting applications
- Horizontal Bracket Orientation — Designed specifically for horizontal speaker wall mount configurations
- 128 x 90 mm Bearing Plate — Generous bearing surface for stable speaker support
- M6 Mounting Pattern — 107.9 x 50.8 mm bolt pattern accommodates a broad range of compatible installation speakers
- Mounting Template Included — Simplifies accurate wall layout and drilling for faster, more precise installation
- Lightweight at 0.2 kg — Minimal added weight to the overall mounting assembly
Technical Specifications
| Bearing Plate | 128 x 90 mm |
| Mounting Pattern | 107.9 x 50.8 mm, M6 |
| Material | Steel |
| Weight | 0.2 kg |
| EAN | 4016842828210 |
